Labels counting rewinding machine roll-to-roll rewinder equipment

Description:

• Model GP-RW01
• Maximum label outer diameter ：φ 300mm
• Label roll core :φ 76mm/φ 152m/φ 300MM
• Maximum label width：150m/200MM/300MM
• Linear velocity range ：20~40min/pcs
• Voltage&Power：220V 50~60Hz 1500W
• Weight ：75 KG; Package weight: 95KG
• Dimension ：650*550*550mm（L*W*H）

1. The main parts of the label counting machine are all imported. Adopting stainless steel and aluminium alloy makes its appearance beautiful and artistic.
2. The label counting machine consists of stepping motor, electron digital computer, optoelectronic switch etc.
3. The counter of the label counting machine is display counter.

Application
This Automatic Label Counting Machine is widely used to count kinds of soft materials in roll form, such as plastic film, paper, medical gauze, non-woven fabric , aluminum foil, etc
Main Technical Parameters:
• Maximum label outer diameter ：φ 300mm
• Label roll core :φ 76mm/φ 152m/φ 300MM
• Maximum label width：150m/200MM/300MM
• Linear velocity range ：20~40min/pcs
• Voltage&Power：220V 50~60Hz 1500W
• Weight ：75 KG; Package weight: 95KG
• Dimension ：650*550*550mm（L*W*H）
It is mainly used in various operations such as printing ,post-cutting label semi-finished product or finished product , counting,cutting,inspection,splicing and other functions.

labels rewinding machine model GP-RW01

1.install label belt
First the label volume of the rewinding will be installed on the label tray, adjust the label limit to the best position, and lock it. Through the right of the scroll through the right shot, the rolling shaft of the loading disc goes through the back of the disc to the collecting tray, and then the paper roll is attached. Limit the bottom of the label with a limit set. The machine is in standby mode。
2.wind label schematic

3.Start power switch
4 amplifier, fiber optic adjustment：set the parameters of amplifier and adjust the position of fiber optic.
5.guide label：start the running switch to adjust the speed to make the label run the positive label. The label guide is limited to the limit circle to prevent the deviation of the label
6.set up output：set the number or length of the rewinding label on the counter, and adjust the speed counterclockwise at the desired speed to achieve the desired speed and the counter accurately counts.
7．Counter tuning need to set the number of labels to adjust the number of tabs, the first digit in the left, and the number of keys to adjust the number, and so on. Set it up and count the copies
Technical Parameters of model YX-RW01 labels rewinding machine

Caution when using the machine:

1：Please read this page before operator use this machine。
2：Please be assured that machine is in “close” status on power switch，then operate it according to instruction。
3：This machine need to be cleaned with cloth out of running status,don’t clean with corrosive detergent。
4：Don’t splash the liquid into the electric box，avoid corrosion or short circuit internal electrical components.
5：Check the appearance of equipment whether it has deformation,damage and rust, the rotating axles should be flexible and free of lag.
6：This machine is a single phase AC 220V power connection with a 3-wire flat plug, should be connected to a ground wire 3 plug socket。
Don’t connect to 380V power，or burning machine。
7：The transmission speed range is 0～1000r/m.
