Description:
VFFS pulse packaging machinery with turning hopper pushing opening door volumetric cups measuring grnaules food punch bag sachet packing equipment
Model:GP-380
Max. Film width 180-520mm
Bag length 80-400mm
Bag width 80-260mm
Packaging cubage 1000ml
Packaging speed 5-40bags/min
Packing thickness 0.04-0.08mm
Power supply specification 220V，3kw
Dimension (L)14520 x(W)1000x(H)1650mm
Total weight of machine 450kg
Max. Film width 180-520mm
Bag length 80-400mm
Bag width 80-260mm
Packaging cubage 1000ml
Packaging speed 5-40bags/min
Packing thickness 0.04-0.08mm
Power supply specification 220V，3kw
Dimension (L)14520 x(W)1000x(H)1650mm
Total weight of machine 450kg
It is mainly apply for weighing small granular products & powder, such as salt, rice, sugar, monosodium glutamate, milk powder, fodder, rice powder, white sugar, monosodium glutamate, solid beverage, dextrose, food additive, dyestuff, and so on.
Application materials:
Drawing of packaging machine with lifting turning hopper&pushing door for volumetric cups measuring system:
Whole pictures for packaging machine VFFS model GP-380
Basic description on packaging equipment model GP-380
Applications: puffed food, shrimp, peanut, popcorn, oatmeal, melon seeds, jelly sugar, salt and other granular.
Optional devices: Electronic weighing system, semi automatic feeding device, spiral type powder measruring device and cup measuring device
Features of packaging equipment:
Whole pictures for packaging machine VFFS model GP-380
Basic description on packaging equipment model GP-380
Applications: puffed food, shrimp, peanut, popcorn, oatmeal, melon seeds, jelly sugar, salt and other granular.
Optional devices: Electronic weighing system, semi automatic feeding device, spiral type powder measruring device and cup measuring device
Features of packaging equipment:
volumetric cups measuring system:
FILM ROLL
The machine is with a motor for revising the positon of the film. If the film is not in the center of the film bracket, you can revise it by controlling in the touch screen to make the motor moving left or right. If the bag length can not cut correctly, you also can move the bracket of the sensor easily to correct the tracking position of the eyemark sensor.
The machine is with a motor for revising the positon of the film. If the film is not in the center of the film bracket, you can revise it by controlling in the touch screen to make the motor moving left or right. If the bag length can not cut correctly, you also can move the bracket of the sensor easily to correct the tracking position of the eyemark sensor.
BAG FORMER
Once we adjust the former well, you only need to take out the handles and don't need to adjust the former again. It is very easy and convenient for changing it when you have a few sets of bag formers for different bag sizes.
But in our professional opinion, we don't suggest our customer to use more than 3 sets of bag formers in one machine. You need to change the former often. If the bag sizes are not too much different, you can change the bag length in order to change the bag volume. It is very easy for changing the bag length by the touch screen.
Once we adjust the former well, you only need to take out the handles and don't need to adjust the former again. It is very easy and convenient for changing it when you have a few sets of bag formers for different bag sizes.
But in our professional opinion, we don't suggest our customer to use more than 3 sets of bag formers in one machine. You need to change the former often. If the bag sizes are not too much different, you can change the bag length in order to change the bag volume. It is very easy for changing the bag length by the touch screen.
LARGER TOUCH SCREEN
Big color touch screen and can save 8 groups of parameters for different packing specification.
We can input two languages into the touch screen for your operating,both Chinese and English
Big color touch screen and can save 8 groups of parameters for different packing specification.
We can input two languages into the touch screen for your operating,both Chinese and English
PROXIMITY SENSORS
Once the door is opened, the machine will stop after finishing the last bag. Or we can make the machine stop immediately once the door is opened. It all can be programmed, as what you like.
1. Side film pulling belt, left and right positon correction by power adjusting film carrier, which keeps even film conveyance and bag forming.
2. Simple structure, easy to understand.
3.Two independent sealing cylinders, excellent airtight, transparent sealing.
4.Applied with PLC, color touch screen, high automation, simple operation, simple operation and mainternance. The machine runs smoothly with low noise.
5. Load the film later to make it easy and convenient.
Basic parameter of model GP-380 packaging machinery
Once the door is opened, the machine will stop after finishing the last bag. Or we can make the machine stop immediately once the door is opened. It all can be programmed, as what you like.
1. Side film pulling belt, left and right positon correction by power adjusting film carrier, which keeps even film conveyance and bag forming.
2. Simple structure, easy to understand.
3.Two independent sealing cylinders, excellent airtight, transparent sealing.
4.Applied with PLC, color touch screen, high automation, simple operation, simple operation and mainternance. The machine runs smoothly with low noise.
5. Load the film later to make it easy and convenient.
Basic parameter of model GP-380 packaging machinery
Model:GP-380
Max. Film width 180-520mm
Bag length 80-400mm
Bag width 80-260mm
Packaging cubage 1000ml
Packaging speed 5-40bags/min
Packing thickness 0.04-0.08mm
Power supply specification 220V，3kw
Dimension (L)14520 x(W)1000x(H)1650mm
Total weight of machine 450kg
Configuration of packing machine puffed food with Gas flushing:
Ribbon coding funciton:
Final bag samples:
Packing food application:
Parts of machinery one by one :
Salt Samples:
Wooden case packing for granules volumetric cups packing machine model GP-380:
Order processing steps:
Order processing steps:
